INTRODUCTION
HowtoUsethisManual
ThismanualisdividedintoSections.EachSectionisthendividedintoChapters.Contentspagesareincludedatthe
beginningofthemanual,theninsideeverySectionandinsideeveryChapter.AnalphabeticalIndexisincludedatthe
endofaChapter.PagenumberreferencesareincludedforeverypieceoftechnicalinformationlistedintheChapter
ContentsorChapterIndex.
EachChapterisdividedintofourInformationtypes:
•
TechnicalData(specications)forallthemechanical,electricalorhydraulicdevices,componentsand,assem-
blies.
•
FunctionalData(howitworks)forallthemechanical,electricalorhydraulicdevices,componentsandassem-
blies.
•
DiagnosticData(faultcodes,electricalandhydraulictroubleshooting)forallthemechanical,electricalorhy-
draulicdevices,componentsandassemblies.
•
Servicedata(removedisassembly,assemble,install)forallthemechanical,electricalorhydraulicdevices,
componentsandassemblies.
Sections
Sectionsaregroupedaccordingtothemainfunctionsorasystemsonthemachine.EachSectionisidentiedby
aletterA,B,Cetc.TheamountofSectionsincludedinthemanualwilldependonthetypeandfunctionofthe
machinethatthemanualiswrittenfor.EachSectionhasaContentspagelistedinalphabetic/numericorder.This
tableillustrateswhichSectionscouldbeincludedinamanualforaparticularproduct.
SECTION
A-Hydraulic–Pneumatic–Electrical–ElectronicSystems
B-EngineandPTOIn
C-Transmission,DriveandPTOOut
D-Axles,BrakesandSteering
E-FrameandCab
F-FramePositioning
G-ToolPositioning
H-HitchandWorkingTool
J-ExcavatingandLandscaping
K-CropProcessing
L-FieldProcessing
PRODUCT
TractorsXXXXXXXX
Vehicleswithworkingarms:backhoes,
excavators,skidsteers,.....
XXXXXXXXX
Combines,forageharvesters,balers,....
XXXXXXXXXX
Seeding,planting,oating,spraying
equipment,....
XXXXXXXXX
Mountedequipmentandtools,.....XXXX
84479138A06/06/2011
