Case 1021F - Page 34

Engine-Engineandcrankcase
36.Disconnectthestarterbatterycables(1)andstarter
switchwire(2).
RCPH11WHL049AAR21
37.Disconnectthefollowingfromthecrankcaseventi-
lation/fuellterbracketassembly:
•
Fuelpumpelectricalconnector
•
Watersensorelectricalconnector
•
Groundwire
•
WireharnessP-clamp
•
Crankcaselterinlethose
•
Crankcaselteroutlethose
•
Crankcaselteroilreturnhose
•
Fuelpumpinlettube
•
Fuelpumpoutlettube
38.Removethecrankcaseventilation/fuellterbracket
assembly.
RCPH11WHL040AAR22
39.Labelanddisconnecttheenginecontrolmodule
electricalconnector(1).
RCPH11WHL041AAR23
4739246119/06/2012
10.001/12
