Engine-Engineandcrankcase
16.Installthelowerradiatortube(1).
RCPH11WHL021AAR13
17.Installtheairbox.
RCPH11WHL019AAR14
18.InstallthewireharnessP-clamp(1).
19.Connecttheairintakehose(3).Tightenthehose
clampontheairintakehose(2)toatorqueof4-5
N·m(35-40lbin).
RCPH11WHL018AAR15
4739246119/06/2012
10.001/22
