Engine-Engineandcrankcase
20.Installthelower,rightpanel(1)ontheenginewall.
RCPH11WHL020AAR16
21.Installtheturboinlettube(2).
22.Tightentheairintakehoseclamp(3)toatorqueof4
-5N·m(35-40lbin).
23.Connectthehumiditysensorelectricalconnector(1).
24.Connecttheairlterrestrictionsensorelectricalcon-
nector(4).
RCPH11WHL017AAR17
25.Installtheupperradiatortube(2).
26.Installthebeforeaircoolertube(1).
RCPH11WHL016AAR18
4739246119/06/2012
10.001/23
