Engine-Engineandcrankcase
30.InstalltheA/Ccompressor(2).
31.ConnecttheA/Ccompressorelectricalconnector(1).
32.ConnecttheA/Cpressureswitchelectricalconnector
(4).
33.Connectthealternatorpowerwire(3).Tightenthe
nuttoatorqueof6-8N·m(55-70lbin).
34.Connectthebulkelectricalconnector(5).
RCPH11WHL045AAR22
35.Connecttheenginegroundwires(1).
36.InstallthewireharnessP-clamp(2).
RCPH11WHL043AAR23
37.Connectthefuelreturnline(1).
38.Connectthebatterypositivewire(2)ontheairgrid
heater.
RCPH11WHL042AAR24
