Engine-Engineandcrankcase
39.Connecttheenginecontrolmoduleelectricalcon-
nector(1).
RCPH11WHL041AAR25
40.Installthecrankcaseventilation/fuellterbracketas-
sembly.
41.Connectthefollowingonthecrankcaseventilation/
fuellterbracketassembly:
•
Fuelpumpelectricalconnector
•
Watersensorelectricalconnector
•
Groundwire
•
WireharnessP-clamp
•
Crankcaselterinlethose
•
Crankcaselteroutlethose
•
Crankcaselteroilreturnhose
•
Fuelpumpinlettube
•
Fuelpumpoutlettube
RCPH11WHL040AAR26
42.Connectthestarterbatterycables(1)andstarter
switchwire(2).
RCPH11WHL049AAR27
