Case 1021F - Page 49

Engine-Engineandcrankcase
43.Connectthehoodliftstrutelectricalconnector(2).
44.Sliptheoildipsticktube(1)throughtheenginewall.
InstallthedipsticktubeP-clamp(3).
RCPH11WHL015AAR28
45.Installthebulkheads(2).
46.Installtheafteraircoolertube(1).
RCPH11WHL014AAR29
47.Installthehydrauliclines(1).
RCPH11WHL013AAR30
4739246119/06/2012
10.001/27
