Case 1021G - Page 39

Engine-Engineandcrankcase
10.Loosenandremovetheboltsthatholdthebattery
coverinplaceonboththeleft-handandright-hand
rearofthemachine.
Disconnectthebatterycablefromthebattery.
LEIL16WHL0891AB7
LEIL15WHL1489AA8
11.Opentheaccesscover.
Placeasuitablecontainerbelowradiatordrain,re-
movetheradiatorcapandcoolantdrainplug(arrow)
todraintheenginecoolant.Reinstallthedrainplug
andradiatorcapafterthecoolanthasdrained.
NOTE:seemachinespecicationsforcoolingsystemvol-
ume.
LEIL15WHL0719AB9
12.Opentheaccesscover.
Placeasuitablecontainerbelowtheengineoildrain.
Removethedrainpluganddraintheoilintothecon-
tainer.Reinstalldrainplug.
NOTE:seemachinespecicationsforengineoilsumpvol-
ume.
RCPH11WHL104AAH10
13.Loosentheclampontheairintakehoseundertheair
inletenginehood.
48083742_EN31/07/2018
