Engine-Engineandcrankcase
31.Removethebolts,washersandnuts(2),(3)tounx
fuelpre-lter(1)fromthesupportbracket.
NOTE:payattentiontotheGRD_WIFwirereleaseatthe
location(2);tagthewire.
LEIL17WHL0298AB27
32.Loosentheclamp(2)onthecrankcaseventhose(1).
33.Removethebolt(3)withrelatedwashersandnutto
separatethetwoclamps(4)fromthehosesupport
bracket(5).
34.Loosentheclamp(6)onthecrankcaseventhose(1).
35.Cutthestraps(7).
36.Removethecrankcaseventhose(1).
LEIL15WHL0669AB28
37.LoosentheP-clamps(2)ontheenginetocrankcase
ventlterhose(1).
38.Removetheenginetothecrankcaseventlterhose
(1).
39.Removethedrainhoselter(3)fromthecrankcase
ventlter.
LEIL15WHL0670AB29
40.Loosenthebolts(2)toremovethecrankcasevent
lter(1)fromthemachine.
LEIL15WHL1138AB30
