Case 1021G - Page 45

Engine-Engineandcrankcase
41.Loosenthefournuts(2)andrelatedwashers(3)that
holdthesupportbracket(1)ofthecrankcaseventlter
totherearchassis.
NOTE:oneofthesefournuts(2)isusedtosecurea
P-clampthatholdthewiringharnesstothesupportbracket
(1).
LEIL15WHL1140AB31
42.Removethetwowashersandnuts(5)tounxtheair
intakebracket(1)fromthehydraulictank.
43.Removethesaddle,U-bolt,washersandnuts(2)to
separatetheairintakeupperhose(3)fromtheair
intakebracket(1).
44.Loosentheclamp(4)todisconnecttheairintakeup-
perhose(3).
LEIL17WHL0270AB32
LEIL17WHL0269AB33
45.Taganddisconnecttheairrestrictionswitch(7)from
theaircleaner.Cutthestrap.
46.Loosentheclamps(6)todisconnecttheairintake
hose(3)fromtheplenumandengineturbocharger.
47.Loosentheclamp(5)todisconnecttheairintake
plenum(2)fromtheelbow.
48.Loosentheclamp(4)todisconnecttheairintakeel-
bow(1)fromtheairlterhousing.
LEIL17WHL0268AB34
48083742_EN31/07/2018
10.1[10.001]/12
