Case 1021G - Page 52

Engine-Engineandcrankcase
79.Loosentheoildrainhose(15)andtheO-ring(14)from
theelbow(13).
80.Separatetheenginemountingbrackets(8)fromthe
engine.
Removetheenginebracketupperbolts(11)andthe
relatedwashers(12).
Removetheenginebracketupperbolts(9)andthe
relatedwashers(10).
Separatetheenginemountingbrackets(8)fromthe
enginemountingplate(7).Removethebolt(1),the
washers(2),rubberlowerisolator(3),therubberup-
perisolator(4)thewasher(5)andthenut(6).
LEIL15WHL1326BB58
81.Slowlyraisetheenginefromtherearchassis.Besure
thatallthewireharnessconnectionsandthehoses
havebeendisconnectedandareclearoftheengine.
Guidetheoildrainhosefromtheframeastheengine
islifted.Removetheenginefrommachine.
LEIL15WHL1082AA59
