Engine-Engineandcrankcase
6.Installthetwelveexplatebolts(1).Tightentheex
platebolts(1)toatorqueof33–41N·m(24–30lb
ft).
LEIL15WHL1019AB4
7.ApplyDOW732RTVSILICONECLEARtotheconverter
housingcoverplate(1).
Installtheconverterhousingcoverplate(2).
LEIL15WHL1330AB5
NOTE:step8isrelatedonlytoCASECONSTRUCTION1121G.
8.Turntheywheel(clockwiseasseenfromtheengine
front)untiloneofthetorqueconverterboltslocationis
visiblethroughthehole,andinstallthebolt.Continue
turningtheywheel(clockwise)in30°incrementsto
exposeeachboltlocation,untilallthetwelveboltsare
installed.
Installtheplug(2).Installthecover(1).
LEIL15WHL1502AB6
9.Holdthecenterdriveshaft(2)inpositionandinstall
thebolts(1)thatfastenthecenterdriveshaft(2)tothe
transmission.
Tightentheboltstoatorqueof136–149N·m(100–
110lbft).
LEIL15WHL1207AB7
48083742_EN31/07/2018
10.1[10.001]/21
