Case 1021G - Page 58

Engine-Engineandcrankcase
21.Connectthezinclowerradiatortube(2)totheelbow
radiatorhosewiththeclamp(1).Torquetheclampto
10.1–11.3N·m(7.4–8.3lbft).
Installthezinclowerradiatortube(2)totheengine
withtwoboltsandwashers(arrows).Useanew
O-ringatthetube-enginejoining.
LEIL17WHL0253AB19
22.Connecttheheaterreturntube(2)tothezinclower
radiatortube(1).
Connecttheheatersupplytube(3)totheengine.
Torqueto21–27N·m(15.5–19.9lbft).
Installthebracket(5)totheenginewithboltsand
washers(7),(8).InstallthetwoP-clamps(4)tothe
bracket(5)withboltandwasher(6),sotosecurethe
heatersupplyandreturntubes(3),(2).
LEIL17WHL0255AB20
23.Connecttheheaterreturntube(2)andheatersupply
tube(3)withtheclamps(7).
SecurethetubeswithtwoP-clamps(4)xedtothe
enginewithbolt,washerandnut(1).
SecurethetubeswithtwoP-clamps(4)xedtothe
bracket(6)withboltandwasher(5).
LEIL17WHL0256AB21
24.Installthebrackets(3)and(4)totheengineblockwith
twoboltsandwashers.
25.Connectthellhose(2)totheenginethroughthe90°
elbow(1).UseanewO-ringandLoctite592sealant.
26.Connecttheengineventhose(5)totheenginewith
theclamp(6).Torquetheclampto1.1N·m(0.8lbft).
27.InstalltheP-clamp(7)tothebracket(3)withbolt,
washersandnutandsecurethellhose(2).
28.InstallthetwoP-clamps(8)tothebracket(4)with
bolt,washersandnutandsecurethellhose(2)and
engineventhose(5).
29.Securethellhose(2)andengineventhose(5)with
thecableties(9).
LEIL17WHL0264AB22
48083742_EN31/07/2018
10.1[10.001]/25
