Case 1121F - 1 - GENERAL INFORMATION; Note to the Owner

INTRODUCTION
Torque
1021FINT ,1121FINT
Alternator
Alternatorpulleyretainingnut
95-109N·m(70-80lbft)
Batteryterminalnut
6-8N·m(55-72lbin)
Indicatorlightterminalnut
2-3N·m(16-24lbin)
Axle
Planetarycarrierlockscrews
200N·m(148lbft)
Brakespringretainercover
34N·m(25lbft)
Axlewheelendscrewplug
50N·m(37lbft)
NutSecuringBrakeTubetoConnector100N·m(74lbft)
BrakeTubeFittingtoWheelEndFitting
36N·m(27lbft)
Axlehousingbolts
560N·m(413lbft)
Inputangeslottednut1200N·m(885lbft)
Differentialreleasinghousingcoverbolts185N·m(136lbft)
Differentialhousingcoverbolts400N·m(295lbft)
Wheelmountingbolts
644-719N·m(475-530lbft)
Axlebreathervalve
4-6N·m(35-53lbin)
Frontaxlemountingbolts
1519-1708N·m(1120-1260lbft)
Reartrunnioncoverbolts
103-115N·m(76-85lbft)
Reartrunnionspacerbolts
285-319N·m(210-235lbft)
Trunnioncastingmounting
651-732N·m(480-540lbft)
Chassis
Cabandcanopymountingbolts773-854N·m(570-630lbft)
Counterweightmountingbolts1125-1261N·m(830-930lbft)
Lowerstepsupportbolts
27-31N·m(20-23lbft)
Batteryholddownbolts
651-732N·m(480-540lbft)
Cooling
Coolingframemounting271-298N·m(200-220lbft)
Fanmountingnut
109-122N·m(80-90lbft)
Drivetrain
Flexplatetoywheelbolts33-41N·m(24-30lbft)
Carrierbearingbolt149-163N·m(110-120lbft)
Drivelinemountingbolts
136-149N·m(100-110lbft)
Transmissionsightgaugemountingbolts
3-5N·m(24-48lbin)
Transmissionshockmountnuts
929-1044N·m(685-770lbft)
Transmission-to-bracketbolts
1125-1275N·m(830-940lbft)
Transmission-to-ywheelhousingbolts54-60N·m(40-44lbft)
Transmissionlltubebolts17-33N·m(151-292lbin)
Banjotubebolt
160N·m(118lbft)
Bypassvalvehoseclamps
10-11N·m(90-100lbin)
Engine
Airintakehoseclamps
4-5N·m(35-44lbin)
Aspiratorhoseclamps
3N·m(30lbin)
Muferextubeclamp18-22N·m(13-16lbft)
Muferclampatturbo5-6N·m(44-53lbin)
Startermotormountingbolts41-48N·m(30-35lbft)
Enginesupportbracket-to-rearchassisbolts
386-434N·m(285-320lbft)
Engineshockmountnuts
397-447N·m(293-330lbft)
