INTRODUCTION
Fueltank
Tightenthefuelsenderboltsinthesequenceasshownintheimage(2)toatorqueof6-8N·m(53-71lbin).
RCPH11WHL117AAR1
Fuelsendermountingbolts
6-8N·m(53-71lbin)
Fueltankskidplatebolts(boltsandnutsaretobe
torquedonlyonetime.Replaceasnecessary)
122-164N·m(90-121lbft)
Fueltankmountingbolts(boltsandnutsaretobe
torquedonlyonetime.Replaceasnecessary)
301-407N·m(222-300lbft)
Hydraulics
Priorityvalvemountingbolts
85-102N·m(63-75lbft)
Mainhydraulicpumpelbow
85-102N·m(63-75lbft)
Hydraulictanksightgaugemounting
3-6N·m(27-53lbin)
Surgetankhoseclampmounting48N·m(35lbft)
Brakepumpmountingbolts
149-170N·m(110-125lbft)
Hydraulicoiltanksuctionhoseclamps
10-11N·m(90-100lbin)
Split,halfclampangebolts(hydraulictank-to-pumps
andpriorityvalve-to-pump)
73-90N·m(54-67lbft)
Split,halfclampangebolts(priorityvalve-to-loader
valve)
198-242N·m(146-179lbft)
Pumpmountingbolts
149-170N·m(110-125lbft)
4739246119/06/2012
