Case 1150M - Torque - Special Torques

INTRODUCTION
Torque-Specialtorques
1150MNA
Ripper
Component
Torque
Rippermountingbolts
700–1260Nm(515–925lbft)
Ripperpinretainingandtubecoverbolts
145–260Nm(110–190lbft)
HydraulicPump
Component
Torque
NonPTOpump
Coverbolts66–80Nm(50–60lbft)
PTOtypepump
Airvent
9Nm(80lbin)
Pumphousingbolts
271Nm(200lbft)
PTOshaftretainer68Nm(50lbft)
SetscrewPTOshaftretainer9Nm(80lbin)
Shaftcoverscrews8–9Nm(65–75lbin)
FuseandRelayBlocks
Component
Torque
Fuseblockmounting
2.7Nm(24lbin)
Bussedstuds
8.5Nm(75lbin)
PowerRelays
Component
Torque
Outputstuds5.4Nm(48lbin)
Inputstuds
16.3Nm(144lbin)
EngineMounts
Component
Torque
Enginemountboltstochassis
205–230Nm(151–170lbft)
Rearenginemountbracketstobellhousing
118–133Nm(87–98lbft)
Frontenginemountbrackettoengineblock
118–133Nm(87–98lbft)
Startermountingbolts68–77Nm(50–57lbft)
EnginetoPumpsDriveShaft
Component
Torque
Flywheelmountbolts
285–305Nm(210–225lbft)
PumpsandMotors
Component
Torque
Pumpmountboltstoframe68–81Nm(50–60lbft)
Motormountboltstonaldrives250–280N·m(184–207lbft)
Pumptomotorhosesspitangeclamps90–100Nm(66–74lbft)
Inlethoseclamps
6.5–7.6Nm(58–68lbin)
RearFrameCover
Component
Torque
M24hexbolts
449–725N·m(331–535lbft)
M16hexbolts
230–371N·m(170–274lbft)
4808003331/01/2017
37
