INTRODUCTION
Track
Component
Torque
Masterlinkbolts(UseLOCTITE®242®onmasterlink
bolts.)
340.0–380.0N·m(250.8–280.3lbft)
Standardlinkshoebolts381.0–435.0N·m(281.0–320.8lbft)
FinalDrives
Component
Torque
DriveHubRollingTorque
8–15N·m(71–133lbin)
InputShaftBearingRetainerPlateMountingBolts77–87N·m(57–64lbft)
ParkBrakeHousingPlate
77–87N·m(57–64lbft)
BrakeHousingCover-M20X5012pnt650–730N·m(479–538lbft)
BrakeLineFitting
55–60N·m(41–44lbft)
BrakeBleederFitting
24–30N·m(18–22lbft)
CounterShaftBearingRetainerPlateMountingBolts125–150N·m(92–111lbft)
SpindleHousing310–380N·m(229–280lbft)
RingGearRetainingPlate310–380N·m(229–280lbft)
SunGearShaftRetainingPlate125–150N·m(92–111lbft)
OutputGearBearingRetainerPlateMountingBolts125–150N·m(92–111lbft)
PlanetaryCarriertoDriveHub310–380N·m(229–280lbft)
FinalDrivetoFrameMountingBolts
656–725N·m(484–535lbft)
FillCheckPlug24–30N·m(18–22lbft)
DrainPlug
24–30N·m(18–22lbft)
CabMounting
Component
Torque
Supportmountbolts733–854N·m(541–630lbft)
Brushguardmountbolts(ifequipped)587–794N·m(433–586lbft)
AirConditioningCompressor
Component
Torque
Compressorrotorshaftnut15–20Nm(11–15lbft)
Oilllerplug15–24Nm(11–18lbft)
Dustcoverscrews
7–11Nm(5–8lbft)
LiftCylinder
Component
Torque
Pistonbolt
1820–1600N·m(1342–1180lbft)
Gland135–542Nm(100–400lbft)
TiltCylinder
Component
Torque
Pistonbolt
2160–2450N·m(1593–1807lbft)
Gland135–542Nm(100–400lbft)
AngleCylinder
Component
Torque
Pistonbolt
2160–2450N·m(1593–1807lbft)
Gland135–542Nm(100–400lbft)
RipperCylinder
Component
Torque
Pistonbolt
1600–1820N·m(1180–1342lbft)
Gland135–542Nm(100–400lbft)
