INTRODUCTION
Starter
Component
Torque
Mountingbolts
68–77Nm(50–57lbft)
Batteryterminalnut
17.7–24.5Nm(13–18lbft)
Solenoid+screw2.6–4.5Nm(23–40lbin)
Multifunctionvalve
Component
Torque
Brakevalve
3–4N·m(2–3lbft)
Brakevalvescrews
3–4N·m(2–3lbft)
Cartridgevalve32.6–35.4N·m(24.0–26.1lbft)
Checkvalve150–177N·m(111–131lbft)
