Case 1850K - TECHNICAL DATA 1850 K - PERFORMANCE; MAX. SPEEDS; MAX. TOW BAR PULLING EFFORT; CLIMBING CAPACITY (FWD)

Carefully read personal and machine SAFETY PRECAUTIONS at the beginning of this Manual
GENERALITIES0 - 8 1850K
TECHNICAL DATAS LT/XLT LGP
Max. speeds
FORWARD
1
st
km/h (mph) 4.3 (2.7) 4.3 (2.7)
2
nd
km/h (mph) 6.7 (4.1) 6.7 (4.1)
3
rd
km/h (mph) 10.9 (6.8) 10.9 (6.8)
REVERSE
1
st
km/h (mph) 5.2 (3.2) 5.2 (3.2)
2
nd
km/h (mph) 8.4 (5.2) 8.4 (5.2)
3
rd
km/h (mph) 13.0 (8.1) 13.0 (8.1)
Max. tow bar pulling effort
FORWARD
1
st
kN (lb x 1000) 290 (65.2) 305 (68.600)
2
nd
kN (lb x 1000) 165 (37) 174 (39.115)
3
rd
kN (lb x 1000) 93 (21) 99 (22.200)
REVERSE
1
st
kN (lb x 1000) 228 (51.255) 240 (53.950)
2
nd
kN (lb x 1000) 129 (29) 136 (30.575)
3
rd
kN (lb x 1000) 72 (16.185) 76 (17.085)
Climbing capacity (FWD)
LT/XLT LGP
1
st
3 km/h (1.87 mph) 3.3 km/h (2.1 mph) % 60
2
nd
5 km/h (3.1 mph) 5.6 km/h (3.5 mph) % 30
3
rd
9.0 km/h (5.6 mph) 9.6 km/h (6.2 mph) % 10
Front equipment cycle times (ref. semi-U blade)
Raising time (from ground to max. height) sec 2.9
Power down (from max. height to ground) sec 1.4
Floating sec 1.4
Noise
Outside (2000/14/CE)LwA dB(A) 111
Back-up alarm.
Left safety lever.
It blocks the equipment, cuts-off the transmission and engages the parking brake.
Right safety lever.
It blocks the equipment, cuts-off the transmission and engages the parking brake.
TECHNICAL DATA 1850K
PERFORMANCES
SAFETY DEVICES
TRACK ON GROUND SHOES WEIGHT CONTACT AREA GROUND PRESSURE
mm mm Kg cm
2
kPa
LT 2700 560 610 20377 20530 30240 32940 66.1 61.1
XLT 3200 560 610 21458 21630 35840 39040 58.7 54.4
LGP 3200 762 915 22204 22730 48768 58560 44.7 38.1
