GENERALITIES1850K 0 - 11
Fan (Blowing) / Soundproof blowing fan TRUFLO ABB
Fan diameter mm (in) 762 (30) 704 (27.7)
Blade pitch deg 26 27
Number of blade - 6 6
Dimension of blades mm (in) 178x258 -
(7x10.2)
Drive ratio (fan/engine) - 0.87:1 0.87:1
Air cleaner
Brand Donaldson
Type FHG12-0345
Dry type, two stages with safety element
and centrifugal separator.
Setting of clogging indicator bar (in H
2
O) 0.062 (25)
Initial clogging (@ 13 m
3
/min) bar (in H
2
O) 0.023 (9.4)
Dust containment capacity (@ 13 m
3
/min) gr./CFM 21
Dimensions mm (in) 304.8 (12)
Pre-cleaner
Rotor/centrifuge assembly, it uses centrifugal force
to separate contaminants carried by the air efficiency 85%
Recommended operation range lt/min (CFM) 9910.9 to 19821.8
(350 to 700)
Silencer Donaldson
Horizontal type. Under hood.
Dimensions mm (in) 155x257x600
(6.1x10.1x23.6)
Max. counter-pressure bar (mmHg) 0.10 (75)
Total volume lt (gal.) 400 (106)
Specifications of filler cap -
Brand: Twin Disc
Model: 15" MS 335
Type: Single stage, rotating housing
Stall ratio - 2.28 : 1
Nominal diameter mm (in) 381 (15)
Setting of pressure relief valve @ 10 lt/min (2.642 gpm) bar (psi) 10.5 (152.3)
Nominal flow of transmission pump @ 17 bar (246.5 psi) lt/min (gpm) 66.0 (17.4)
Nominal flow of TC @3 bar (43.5 psi) lt/min (gpm) 116.0 (30.6)
Wet TC housing with scavenger pump
Type: countershafts
Model: TM 200
Make: CNH
TORQUE
CONVERTER
AND
HOUSING
FUEL TANK
TECHNICAL DATA 1850K
ENGINE AND
ACCESSORIES
