Carefully read personal and machine SAFETY PRECAUTIONS at the beginning of this Manual
GENERALITIES0 - 12 1850K
Specifications: 3 + 3 speeds, speeds and direction modulation valves
electronic controls + automatic mode
integrated CPU and TM control.
PTO capacity
Max. torque @ 0 rpm daNm (lb.ft.) 169 (1246)
Max. speed @0 torque rpm 2183
Specifications:
Clockwise rotation (from rear of machine) driven by Torque Converter.
Shaft specifications:
Number of teeth - 21
Module mm (in) 1.58 (0.06)
Outer diameter mm (in) 34.87 (1.37)
Filters:
Suction:
Metal mesh + magnetic rod mesh 100
Line:
Screwed-on Micron 25 abs.
Setting of by-pass valve bar (psi) 3.44 (49.9)
Collecting capacity @ 3.44 bar (49.9 psi) (ISO 4572) gr. (lb) 50 (0.1)
Filtering area cm
2
(in
2
) 3075 (476.6)
Loss of charge @ 80lt/min (21.1 gpm) bar (psi) 0.71 (10.3)
Nominal pressure of element bar (psi) 34.5 (500.4)
Rupture pressure of element bar (psi) 70 (1015.3)
Setting of transmission regulation valve @ 66lt/min (17.4 gpm) bar (psi) 17 (246.6)
Oil radiator body in aluminum mm (in) 310x1010x150 (12.2x39.8x5.9)
Controls:
Joystick, Shift up-down slider button.
FWD & REV actuated thru pressure switches on the joystick.
Description of auto mode
AL Down-shifting of transmission when the engine slows down to a pre-determined speed.
AS Allows the operator to pre-select the 1
st
speed in forward and the 2
nd
in reverse at
direction changes.
Dimension of shaft
Mechanical 7C
Nominal length mm (in) 425 (16.7)
Gleason type, modular pinion assembly. Forced lube pinion bearings.
Ratio: 17/36
Module: mm (in) 10 (0.4)
TECHNICAL DATA 1850K
TRANSMISSION
PROPELLER
SHAFT
BEVEL GEAR
GROUP
