SECTION 55 - ELECTRICAL - CHAPTER 1
55-2
The header electrical system includes flashers,
automatic head height control potentiometers, a
header type sensor, and a wire harness to connect
these items to the combine. Wiring schematics for
repair and troubleshooting are available in the
combine Repair Manuals.
The flashers, 1, are located on both sides of the head
10007619
1
1
On the 2020 heads, the head height control
potentiometers, 1, are located on both sides of the
head.
50023022
1
2
On the 2010 heads, the head height control
potentiometers, 1, are located between the head and
the left and right end protection plates.
50023060
1
3
