INTRODUCTION
AirConditioningCompressor
Component
Torque
Compressorrotorshaftnut15-20Nm(11-15lbft)
Oilllerplug15-24Nm(11-18lbft)
Dustcoverscrews
7-11Nm(5-8lbft)
LiftCylinder
Component
Torque
Pistonbolt
2160-2450N·m(1593-1807lbft)
Gland135-542Nm(100-400lbft)
TiltCylinder
Component
Torque
Pistonbolt
2160-2450N·m(1593-1807lbft)
Gland135-542Nm(100-400lbft)
AngleCylinder
Component
Torque
Pistonbolt
2160-2450N·m(1593-1807lbft)
Gland135-542Nm(100-400lbft)
RipperCylinder
Component
Torque
Pistonbolt
2830-3210N·m(2087-2368lbft)
Gland135-542Nm(100-400lbft)
Starter
Component
Torque
Mountingbolts
68-77Nm(50-57lbft)
Batteryterminalnut
17.7-24.5Nm(13-18lbft)
Solenoid+screw2.6-4.5Nm(23-40lbin)
Multifunctionvalve
Component
Torque
Brakevalve
3-4N·m(2-3lbft)
Brakevalvescrews
3-4N·m(2-3lbft)
Cartridgevalve32.6-35.4N·m(24.0-26.1lbft)
Checkvalve150-177N·m(111-131lbft)
Powertrainspecications
Component
Torque
Cradletochassisfront185-200N·m(136-148lbft)
Cradletochassisrear70-80N·m(52-59lbft)
Hydrostaticmotormountingboltstoparkbrakehousing
250-280N·m(184-207lbft)
Enginetocoupler
41-50N·m(30-37lbft)
Tandempumptocradlerearmountingbracket
265-305N·m(195-225lbft)
Hydrostaticpumptopumpmountingplate
587-690N·m(433-509lbft)
Pumpcouplerretainerplate
136-156N·m(100-115lbft)
Cradlemidmount225-305N·m(166-225lbft)
Enginetocradlefront107-123N·m(79-91lbft)
