INTRODUCTION
O-ringfacesealend
Nom.SAE
dashsize
TubeOD
ThreadsizeNewton
metres
lb/inlb/ft
-46.4mm
1/4inch9/16-18
23to26204to228
-69.5mm
3/8inch11/16-16
34to40300to348
-812.7mm
1/2inch13/16-16
52to57456to504
-1015.9mm
5/8inch
1-1481to90720to792
-1219.0mm
3/4inch1-3/16-12
117to12886to94
-1625.4mm1.0inch
1-7/16-12
152to174112to128
-2031.8mm
1-1/4inch1-11/16-12
179to201132to148
-2438.1mm
1-1/2inch
2-12213to235157to173
O-ringbossendttingorlocknut
Nom.SAEdashsize
ThreadsizeNewtonmetres
lb/inlb/ft
-6
9/16-18
48to54432to480
-8
3/4-16
70to78612to684
-10
7/8-14
102to11475to84
-12
1-1/16-12
142to160105to117
-16
1-5/16-12
237to254175to187
Pipetting
Non.SAEdashsize
Threadsize
TFFT(TurnsForFingerTight)
-2
1/8-27
2.0-3.0
-3
1/8-27
2.0-3.0
-4
1/8-27
2.0-3.0
-5
1/8-27
2.0-3.0
-6
1/4-18
1.5-3.0
-8
3/8-18
2.0-3.0
-10
1/2-14
2.0-3.0
-12
3/4-14
2.0-3.0
-14
3/4-14
2.0-3.0
-16
1-11-1/2
1.5-2.5
-20
1-1/4-11-1/2
1.5-2.5
-24
1-1/2-11-1/2
1.5-2.5
-32
2-11-1/2
1.5-2.5
NOTE:Applyasealant/lubricanttothemalepipethreads.Thersttwothreadsshouldbeleftuncoveredtoavoid
systemcontamination.Screwthepipettingintothefemalepipeporttothengertightposition.Wrenchtightenthe
ttingtotheappropriateturnsfromngertight(TFFT)shownintheableabove.Makesurethetubeendofanelbow
orteettingisalignedtoreceivetheincomingtubeorhosetting.
