Case 2050M - Page 50

Engine-Engineandcrankcase
Engine-Install
2050MLA
Prioroperation:
Engine-Remove(10.001)
1.Attachthetandempumpexiblecouplingassemblyto
theywheel.T orquetheboltsto41-50N·m(30-37lb
ft)
2.Slowlylowertheengineintotheframecradleandcon-
necttheenginetothehydrostaticdrivepumpstack.
3.Installthemountingboltsandwashers(1)intotheen-
gine-to-pumpstackadapterplate(2).T orquethebolts
to46-62N·m(34-46lbft).
RAIL14DOZ0203AA1
4.Usealevelandverifythattheenginemountingframe
cradleissittingonalevelsurface.
NOTE:Beforeapplyingthetorquetothemidengine-to-framecradlemountbracketboltsandthefrontengine-to-
mountframecradleboltstotheirnalspecication,makesurethattheframecradleislevel.
5.Installtherightsideengine-to-framecradlemounting
bracket.ApplyLOCTITE®242®totheengine-to-frame
cradlemountingbracketbolts.Torquethethreebolts
(1)91-123N·m(67-91lbft)totheadapterplate,and
thethreebolts(2)225-305N·m(166-225lbft)tothe
rightsideengine-to-framecradlemountingbracket(3).
RAIL14DOZ0202AA2
7111454816/03/2015
10.1[10.001]/5
