CHAPTER 1 - GENERAL INFORMATION
1-4
Issued 9-06 Bur 87538948NA
MACHINE COMPONENTS
BD06G105
Figure 8
1. Cab 5. Track 9. Right-hand Engine Access
Door and Side Shield Panel
2. Right-hand Rear Access
Door
6. Carrier Rollers 10. Blade
3. Right-hand Center Access
Door
7. Track Roller 11. Radiator Door
4. Sprocket 8. Idler 12. Hand Holds
3
2
7
5
10
1
4
6
6
8
11
12
12
9
