Engine-Engineandcrankcase
13.Removethesupportbracketoftheenginecoolant
overowtank.
LEIL16WHL0575AB13
14.Removethecoolingfanguard.
LEIL17WHL0137AB14
15.Loosenthefourboltstoremovetheengineguard(1).
LEIL17WHL0118AB15
16.Disconnectthecrankcaseventhosefromtheengine.
LEIL17WHL0136AB16
48083741_EN31/07/2018
10.1[10.001]/8
