Engine-Engineandcrankcase
24.TaganddisconnecttheST,CPWRandbatteryposi-
tivecables(1)fromtheenginestarter.
Taganddisconnectthenegativebatterycable(2),
groundstrap(3)andXM1Ccable(4)fromtheengine
starter.
TaganddisconnecttheGND_ENG1,GND_ENG3,
GND_ENG4cables(5)andGND_CENG1,
GND_CENG2cables(6)fromtheengine.
LEIL17WHL0114AB25
25.Taganddisconnectthebreatherline(hoseandvent-
ingcheckvalve)fromtheengine.
LEIL17WHL0094AB26
26.RemovetheU-boltclamptounxthetopcoolingline
fromthemufersupportstructure.
LEIL17WHL0095AB27
27.Removetheclamps(2)todisconnectthetopcooling
line(1)fromtheelbowhoseandengine.Tagthehose.
LEIL17WHL0093AB28
