Case 521G - Page 55

Engine-Engineandcrankcase
71.Cutthetiestraps(1)andremovetheclamp(4).Sep-
aratethebreatherhose(3)fromtheradiatorhose(2).
Loosenclamp(6)fromthehose(5).Loosenclampon
theenginethenremovethehose(5).
LEIL15WHL0279AB65
72.Removethenuts(2)fromtheU-boltclamp,tosepa-
ratetheradiatorhose(3)fromthebracket(1).
LEIL15WHL0280AB66
73.Removetheclamp(1)todisconnectthebreatherhose
(2)fromtheengine.
LEIL15WHL0291AB67
74.Removethebolts(1),thewashers,andthenutstore-
movethebracket(2)fromtherearplateofthecooling
systemframe.
LEIL15WHL0292AB68
