Engine-Engineandcrankcase
80.Removetheclamp(1)andextracttheupperradiator
hose(2).
LEIL15WHL0297AB73
81.Removethecoolanthose.
Plugthelineandcapthetting.
LEIL15WHL0306AB74
82.Tagandremovethegridheatercable.
NOTE:holdtherearnutwithasecondwrenchtoprevent
gridheaterdamage.
RAPH12WEL1478AA75
83.Disconnectthewiringfromthealternator.Identifyand
tagthewirestoaidinreassembly.
NOTE:movethewiresawayfromtheengine.
RAPH12WEL1468AA76
