ENGINE REMOVAL
2000-7
Put identification tags on all disconnected hoses and
wires. Close disconnected hoses and fittings with
caps and plugs.
STEP 1
Remove the radiator see page 4.
STEP 2
Disconnect the battery.
STEP 3
CI98G518
Remove the hose clip (4) from the air filter hose (5) at
the turbocharger inlet.
STEP 4
Support the air filter assembly (1) and remove the
three bolts (2) from the cylinder head and two bolts
(3)
from the exhaust bracket. Remove the air filter
assembly.
STEP 5
66
2
789M257A
789M256A
Install the engine lifting bracket (6) using two of the
bolts (2) from the air filter bracket. The bracket is part
of the machine tool kit.
Cre 7-21290GB Issued 10-99
