Case 865B - O-Ring Face Seal End Fittings; O-Ring Boss End Fittings

6-46530 ENG Issued 07-11 Printed in Brazil
1001-6
Steel Hydraulic Fittings
Nom. SAE
Dash
Size
Tube OD
INCH
(mm)
Thread
Size
Pound-
Inches
N.m
Thread
Size
Pound-
Inches
N.m
O-RING FACE SEAL END
O-RING BOSS END
FITTING OR LOCk NUT
- 4
1/4
(6.4)
9/16-18 10 - 12 14 - 16 7/16-20 17 - 20 23 - 27
-6
3/8
(9.5)
11/16-16 18 - 20 24 - 27 9/16-18 25 - 30 34 - 41
-8
1/2
(12.7)
13/16-16 32 - 40 43 - 54 3/4-16 45 - 50 61 - 68
-10
5/8
(15.9)
1 - 14 46 - 56 62 - 75 7/8-14 60 - 65 81 - 88
-12
3/4
(19.0)
1-3/16-12 65 - 80 90 - 110 1-1/16-12 85 - 90 115 - 122
-14
7/8
(22.2)
1-3/16-12 65 - 80 90 - 110 1-3/16-12 95 - 100 129 - 136
-16
1.0
(25.4)
1-7/16-12 92 - 105 125 - 140 1-5/16-12 115 - 125 156 - 169
-20
1-1/4
(31.8)
1-11/ 16-12 125 - 140 170 - 190 1-5/8-12 150 - 160 203 - 217
-24
1-1/2
(38.1)
2-12 150 - 180 200 - 254 1-7/8-12 190 - 200 258 - 271
