Case 885B AWD - Powershift Transmission Torque Specifications

Transmission-Powershifttransmission
Powershifttransmission-Generalspecication
845BT orqueconvertertransmission,Tier3,madeinBrazil
[HBZN0845VCAF01093-]
(6x3torqueconverter)OR(Tier1)OR(Tier3-VHP)
865BT orqueconvertertransmission,Tier3,madeinBrazil[NBAF14004-]
(6x3torqueconverter)OR(Tier2)OR(Tier3-VHP)OR(Tier0)
Conversiontable
25.40mm
=
1in
1kg
=
2.205lb
9.81N·m(1kpm)
=
7.233lbftxft(poundforceperfoot)
1.356N·m(0.138kpm)
=
1lbftxft(poundforceperfoot)
1Kg/cm
=
5.560lbin(poundperinch)
1bar(1.02kp/cm2)
=
14.233psi
0.070bar(0.071kp/cm2)
=
1psi
1l
=
0.264USgal(Imp.)
4.456l
=
1USgal(Imp.)
1l
=
0.220USgal(USA)
3.785l
=
1USgal(USA)
1609.344m
=
1Mile(landmile)
0°C
=
+32°F
0°C
=
273.15Kelvin
Powershifttransmission-Torque
845BT orqueconvertertransmission,Tier3,madeinBrazil
[HBZN0845VCAF01093-]
(6x3torqueconverter)OR(Tier1)OR(Tier3-VHP)
865BT orqueconvertertransmission,Tier3,madeinBrazil[NBAF14004-]
(6x3torqueconverter)OR(Tier2)OR(Tier3-VHP)OR(Tier0)
Tighteningtorquesforthebolts
Frictioncoefcient:µtot.=0.12fortheplugsandnutswithoutreworking,aswellasforthephosphatednuts.Leave
ngertight.
Taketighteningtorquesfromthefollowingchart,unlessotherwisespecied:
MetricISOstandardthreadDIN13.
Dimension8.810.912.9
M42.84.14.8
M5
5.5
8.19.5
M69.51416.5
M7152328
M8233440
M10466879
M1279115135
M14125185215
M16195280330
M18280390460
M20390560650
M22530750880
M246709601100
M27100014001650
M30135019002250
M33185026003000
M36235033003900
M39300043005100
48050419D06/10/2017
21.1[21.113]/7
