LUBRICATION & MAINTENANCE CHART
845B / 865B / 885B Models Equipped with Tier 0, 1 and 2 Engines
SERVICE POINTS
POINTS
VERIFY
REPLACE
LUBRICATE
ADJUST
CLEAN - DRAIN
As needed
Air cleaner (Note 1) 1 *
Hydraulic lter (Note 2) 1 *
Cab Air Filter (if equipped) 1 *
Batteries (See Electrical System) 2 *
10 hours or
daily
Engine oil level (including lters) 1 10
Radiator (coolant level) (Note 3) 1 10
Transmission oil level (warm, engine running)
(ZF and FUNK Transmission)
1 10
Differential Lock Oil Filter (if equipped) 1 10
50 hours or
weekly
Fuel Reservoir Filter (wash screen) 1 50
Fuel Water Separator (drain water) 2 50
Hydraulic tank (complete system) 1 50
100 hours
or each 15
days
Moldboard Lift Cylinder Pivots 4 100
Moldboard Lift Cylinders Balls 2 100
Moldboard Side Shift Cylinders Balls 2 100
Articulation of Tilt Cylinders 2 100
Moldboard Tilt Pivots 2 100
Articulation Cylinders Pivots 4 100
Articulation Bearings 2 100
Drawbar Ball and Socket 1 100
250 hours
or monthly
Alternator and Air Conditioner Belt 2 250
Universal Joints and Drive Shaft 2 250
Circle Turn Gearbox Oil Level 1 250
Differential Lock Oil Filter (if equipped) 1 250
Front Axle Pivot 2 250
Front Wheel Lean Bar Pivots 2 250
Front Wheel Lean Cylinder Pivots 2 250
Front Wheel Knuckle Lean Pivots 4 250
Knucle King Pin Bearings 4 250
Moldboard Lift Cylinder Articulation Bearings 2 250
Tandem Swing Bearing 2 250
Tires Condition and Pressure 6 250
Cab Air Filter (if equipped) 1 250
Steering Bar Ball Joints 4 250
Moldboard Articulation Pivots 4 250
Moldboard Side Shift Pivots 2 250
Engine Oil and Oil Filter 2 250
To Next Page
