SERVICE POINTS
POINTS
VERIFY
REPLACE
LUBRICATE
ADJUST
CLEAN - DRAIN
500 hours
or each 3
months
Fuel Filters and Water Separator 2 500
Fuel Tank Drain Plug (drain sediment) 1 500
Engine Oil and Oil Filter 2 500
Hydraulic System Oil Filter 1 500
Transmission Oil and Oil Filter (Note 4)
(ZF Transmission – 845B / 865B models)
1 500
Transmission Oil and Oil Filter
(FUNK Transmission – 845B / 865B / 885B models)
1 500
Front Wheel Bearing Grease 2 500
Tandem Wheel Shafts Bearings (Graziano) 8 500
Tandem Case Oil Level 2 500
Rear Axle Differential and Planetary Gear Oil Level (Graziano) 1 500
ROPS Fixing Bolts Torque 16 500
Seat Belts Fixing Bolts Torque 2 500
1000 hours
or each 6
months
Transmission Screen (FUNK Transmission – 845B / 865B / 885B models) 1 1000
Transmission Oil (Note 4) (ZF Transmission – 845B / 865B models) 1 1000
Transmission Oil (FUNK Transmission – 845B / 865B / 885B models) 1 1000
Engine Valves Clearance 12 1000
Circle Turn Gear Housing Oil 1 1000
Alternator and Ar Conditioning Belts 2 1000
Air Cleaner Elements (See Air Cleaner System) 2 1000
Tandem Case Oil 2 1000
2000 hours
or yearly
Rear Axle Differential and Planetary Gear Oil (Graziano) 1 2000
Hydraulic System Oil (Note 5) 1 2000
Engine Coolant 2 2000
Turbocharger Fixing Bolts Torque 4 2000
NOTE: See “FLUIDS AND LUBRICANTS” table on previous pages for lubricants and uids detailed specications and capacities.
NOTE 1: Service the air lter elements if air lter restriction indicator (Non-Critical Warnings – YELLOW) show “air lter”.
NOTE 2: Service the hydraulic lters if hydraulic lter indicator lamp (Non-Critical Warnings – YELLOW) show “hydraulic lter”.
NOTE 3: Check the radiator coolant level if the coolant level warning lamp (Critical Warnings – RED) show “coolant level”.
NOTE 4: Change the transmission uid and replace the lter after the rst 100 hours of operation
NOTE 5: Change every 2.000 hours or once a year, whichever comes rst.
*: As needed.
