FLOW CONTROL VALVE SPRING
Free Length ........................................................................................ 43.18 mm
CHECK VALVE SPRING
Free Length ......................................................................................... 11.68 mm
ACTION (DROP RESPONSE) VALVE SPRING
Free Length ......................................................................................... 43.31 mm
DRAFT CONTROL VALVE
Draft Valve Spring
Free Length ..................................................................................... 80.62 mm
Drop Valve Poppet Spring
Free Length ..................................................................................... 38.74 mm
Drop Valve Spool Spring
Free Length ..................................................................................... 23.37 mm
