Case CX225SR - Right, Left, Front and Rear of the Machine

CHAPTER 1 - GENERAL INFORMATION
1-4
Issued 10-02 Bur 6-34630naNA
RIGHT, LEFT, FRONT AND REAR OF THE MACHINE
CT02D269
Figure 3
1. FRONT
2. REAR
3. RIGHT-HAND SIDE
4. LEFT-HAND SIDE
5. TRAVEL REDUCTION GEARS
6. IDLER WHEELS
The terms Right-hand, Left-left, Front, and Rear are
used in this manual to indicate the sides as they are
seen from the operator's seat when the cab is over
the idler wheels.
The illustration below shows the machine in normal
TRAVEL position. In normal TRAVEL position, the
cab is over the idler wheels. The travel reduction
gears are at the rear of the upperstructure.
1
66
34
55
2
