INTRODUCTION
Torque
Torquespecicationsforcapscrewsandnuts
Thefollowingtorquespecicationsareindicatedincase
theactualtorquevalueofafastenerisunknown.Check
thecapscrewsandnutsfortheirloosenessanddropping
offbeforethestartofdailyworkandattheperiodicalmain-
tenance.Retightentheloosenedones,andinstallnew
onesforthedroppedoff.Forthenewmachine,thecheck
andretighteningofthemmustbecarriedoutatrst50h
operation.Forthereplacementofthem,makesuretouse
thesamesizeofmanufacturer’sgenuineparts.
Refertothetablebelowforthetighteningand
retighteningofcapscrews.
•
Thetablebelowisnotapplicableforthecapscrewsto
xthecover,etc.,madeofplastic.Forthetightening
torqueforsuchcapscrews,consultwithanauthorized
ourDistributor.Over-tighteningmaycausedamages
onthepartstobexed.
•
Iftheoperator’smanualspeciesadifferenttorque,use
suchvalueregardlessofthetablebelow.
•
Numericalindicationonthecapscrewheadshowsthe
classicationforstrength(e.g.,7=7T).Noindication
isprovidedforsmallersizeofcapscrews,M5orless.
