Instructions
Right hand to left hand platform adjustment
A x4
D (5mm)
B x10
2
3
5
D
Re-bolt the back adjustment plates into
the same position on the opposite side
using bolts A.
Two people should turn the lounger
onto its side on a soft at surface.
Remove the back sling and back
adjustment plate.
Required
Provided
Towards centre
of frame.
4
With the frame on its back, remove
and rotate the seat sling 180
degrees.
A x4
B x2
A x4
C x12
B x8
C x8
C x4
D
Place the lounger back onto its side.
Insert the back adjustment bars into
the plates by tilting the backrest
slightly and re-attach the two bolts B
into the correct holes.
C x4
B x2
B x8
C x8
D
180
Re-attach the seat sling at the opposite
end of the frame.
