ADJUSTMENTS AND MAINTENANCE
1, Height Selection Lever: See Figure 4
The mower cutting height is adjustable
from 1-1/2" to 3-1/2" with 112" settings
available in between. To change the
cutting
height, pull outward on the se-
lection knob, move the lever up or down
to desired height setting and push back
into matching hole. Relieve the weight
an the selection lever by raising the
mower into transport position before ad-
justing the cutting height, Always op-
erate the mower with the gauge wheels
on the ground and all weight off the
mower lift Ws to obtain a level and
uniform cut,
/MPRrA#f When the cutting height is
changed, readjust the
Depth Control Knob as ex-
plained in the following .
paragraph for proper
mower flotation.
DEPTH CONTROL
KNOB
DEPTH CONTROL -
ROD \ ""
Figure 4.
