INTRODUCTION
Torquespecicationsforsleevetypetubetting
Sleevetypetubettings
Tubesize
Outside
diameterx
thickness
Wrenchsize
Tightening
torque
10mm(0.4in)
x1.5mm
(0.1in)
19mm
44N·m(32.5lb
ft)±4.9N·m
(3.6lbft)
15mm(0.6in)
x2.0mm
(0.1in)
27mm
147N·m
(108.4lbft)±
20N·m(14.8lb
ft)
18mm(0.7in)
x2.5mm
(0.1in)
32mm
177N·m
(130.5lbft)±
20N·m(14.8lb
ft)
22mm(0.9in)
x3.0mm
(0.1in)
36mm
216N·m
(159.3lbft)±
20N·m(14.8lb
ft)
28mm(1.1in)
x4.0mm
(0.2in)
41mm
275N·m
(202.8lbft)±
29N·m(21.4lb
ft)
35mm(1.4in)
x5.0mm
(0.2in)
55mm
441N·m
(325.3lbft)±
44N·m(32.5lb
ft)
SMIL13MEX0050XA6
47574282B24/03/2014
16
