INTRODUCTION
(10)Emergencystop
Presstostopthemachineandengineinstantlyintheeventofanemergency.
(11)Activeworkingposition
Indicatesfromwhichposition(seat)therollertraveliscontrolled.Ifnoindicatorlamp(11)asheswhentheignition
switchisturnedON,thentheenginecanbestarted.Iftheindicatorlamps(11)ashwhentheignitionswitchisturned
ON,thentheenginecannotbestartedsinceoneortwotravelcontrollersarenotinthe“N”position-idleindicator
lampdoesnotlight.
(12)Sprinklingswitchandintervalcontrol
Turntheswitchlefttosetthepumptoruncontinuously.Thetireswillbesprinkledconstantly.Turntheswitchtoany
offourpositionsinaclockwisedirectiontoturnthesprinklingintervalcontrolON.
Position
SprinklingforStopfor
I10s10s
II10s15s
III10s22s
IV10s33s
NOTE:Thesprinklingindicatorlampisonlylitwhenthepumpisrunning.
(13)EngineControlModule(ECM)diagnosticssocket
ForconnectingtotheEngineControlModule(ECM).Designedtodiagnoseanydefectsortoadjustengineparame-
ters.
SS12D6063
Instrumentsandcontrols
4770368109/09/2015
