INTRODUCTION
Idleswitch
Forenginestart.
Directionsindicators
Multifunctionaldisplay
SS12N0525
Multifunctionaldisplay
1
Warninglight–yellowLEDlights
Alarmforenginefailureorminimalfuellevelintank
2
Engineshut-offlight–redLEDlights
Alarmformajorenginemalfunction
3
Enterbutton
SelectsMenuorparameter,orconceals/displaysactiveerrorcode
4
Right/upnavigationbutton-tomovecursorDOWN
Illuminatesdataonthedisplayormovestheparameteroptiontotherightordown
5
Left/downnavigationbutton-tomovecursorUP
Illuminatesdataonthedisplayormovestheparameteroptiontotheleftorup
6Menuselectionbutton-toenterorexitMenu
7
Displayscreen
