Case Slot - Page 8

Assembly
8
Before attaching the wall boss (A) to the wall, x grub screw (C) to pinch the back end
of pin (B), (section after intended groove). This temporarily secures the pin (B) in place
with additional tolerance for attaching the uprights (J).
B
C
A
Insert pin (B) into hole
that intersects with
threaded top hole for
grub screw (C).
B
A
C
7
7
Ensuring the grub
screw (C) does not
penetrate fully.
