INTRODUCTION
7.Slowlyraisetheloaderarmuntilthesupportstrut(B)
fallsontothecylinderrod(D).
8.Stoptheengine.
9.Pullupontheoverridecontrolknob(redcontrolknob
neartheright-handsideoftheoperator’sseat).The
supportstrut(B)willbraceagainstthetopofthecylin-
derbarrel(C)..
10.Askanassistanttoinsertthepin(A)intothesupport
strut(B).Ifanassistantisnotavailablevisuallycon-
rmthatthesupportstrutisbracedagainstthetopof
thecylinderbarrelbeforeexitingthemachine.
93106854A3
RAIL14SSL0418AA4
Tiltandlockthecabforwardformachineservice
1.Removethetwo,rearretainingnuts,locatedatthe
rearofthecab.
9310016335
4768391627/02/2015
9
