INTRODUCTION
6.Locatetheloaderarmlockleverontheleft-handside
oftheoperator’sseat.
7.Rotatethelocklevertowardtheoperator’sseat(clock-
wise)toengagethelocksupportpin(s).
8.Stoptheengine.
RAIL14SSL0428AA3
9.Pullupontheoverridecontrolknob(redcontrolknob
neartheright-handsideoftheoperator’sseat).The
loaderwillbraceagainstthelocksupportpinandkeep
theloaderarminaraisedposition.
NOTE:Onlyusetheoverridecontrolknobtolowerthe
loaderarminemergencysituationswhenenginepower
isnotavailableortoloweritontothelocksupportpinfor
servicingthemachine.
931074574
Tiltandlockthecabforwardformachineservice
1.Removethetwo,rearretainingnuts,locatedatthe
rearofthecab.
9310016335
4768391627/02/2015
13
