INTRODUCTION
2.Pullonthehandholdsatthefrontofthemachineuntil
thecabiscompletelytiltedforward.
RAPH11SSL0016BA6
3.Conrmthattheredlocktubehasloweredoverthe
cabpivotlinkage.Ifithasthecabtiltpositionisnow
secure.
RAPH12SSL0420BA7
Tiltandsecurethecabformachineoperation
1.Raisetheredlocktubeexposingthecabpivotlinkage.
2.Pushthecabbackwardintotheoperationposition.
RAPH12SSL0420BA8
