Engine-Engineandcrankcase
35.Installtheretainingstraps(1)fortheSCRmufer.
RAIL14SSL0854BA17
36.AttachtheSCRmufer(1)tothemufermounting
bracket.
RAIL14SSL0853BA18
37.Attachtheexhausttube(1)totheSCRmufer.T orque
theclamp(2)to11–15N·m(97–133lbin).
38.SecuretheSCRmufertothemuferbracketbyusing
thehardwarethatwaspreviouslyremoved.
RAIL14SSL0791BA19
4806031928/08/2017
10.1[10.001]/25
