PARTS LIST (M405R)
Item Code No. Parts Name Specification Version Q R
DRIVE MECHANISM COMPONENTS
100 1908 5585 Motor ass'y C770052000 1 A
101 1903 0638 C.B. screw B010350511 2 X
102 1908 5586 First reduction gear C770051010 1 C
TRANSMISSION MECHANISM COMPONENTS
200 1908 7302 Second reduction gear C769101000 1 C
202 1903 2606 Third reduction gear C756101020 1 C
203 1907 6818 Cam gear C761101040 1 C
204 1902 5617 Print transmission gear C405104010 1 C
205 1903 2602 Intermittent transmission gear C753101070 1 C
206 1903 2609 Intermittent gear C756101050 1 C
207 1903 2610 Paper feeding C756101060 1 C
second transmission gear
211 1908 7303 Ribbon feed driving lever C769110010 1 C
212 1903 2611 Selective transmission gear C756101070 1 C
DETECTING MECHANISN COMPONENTS
300 1908 7018 Timing signal detector ass'y C769151000 1 B
301 1908 3468 C.P.(P). screw B041050911 1 X
PRINTING MECHANISM COMPONENTS
400 1908 5587 Charactor selective magnet unit C774201000 1 C
401 1903 0627 C.T.B. screw B013001711 2 X
402 1908 7305 Reset lever ass'y C769204000 1 C
406 1908 5590 Print wheel set M466009280 1 A
407 1903 0793 Retaining ring B150350211 2 X
408 1903 2612 Selective gear C756205010 1 C
409 1903 2186 Print wheel shaft holder C755211010 1 C
410 1903 0767 Plain washer B100154712 1 X
411 1903 0777 Leaf spring B101252590 4 X
412 1908 5588 Platen ass'y C C756210000 1 C
413 1903 1072 Platen holder ass'y C750212000 1 C
414 1902 5660 Crank shaft holder C505227020 2 C
415 1908 7307 Printing gear C769210030 1 C
416 1903 2614 Paper feeding C756206030 1 C
first transmission gear
417 1908 7600 Leaf spring B101250590 1 X
418 1902 5628 Slit mask spring B C405204060 1 C
419 1903 2619 Print wheel guide C C757203010 1 C
PAPER FEEDING MECHANISM COMPONENTS
500 1908 4333 Outer paper guide ass'y C756251000 1 X
501 1908 4334 Inner paper guide C756251020 1 X
502 1902 5865 Paper feeding roller ass'y C408254000 1 C
503 1902 5658 Paper feeding roller shaft spring C501253010 1 C
504 1902 5866 Paper feeding shaft holder B C408254020 1 C
505 1903 0714 Retaining ring B150350111 1 X
506 1902 5661 Paper feeding gear C505252030 1 C
507 1902 5666 Spring pin B130150116 1 X
508 1903 2616 Paper holding roller C756208010 1 X
509 1903 2617 Paper holding spring C756208020 1 C
INKING MECHANISM COMPONENTS
600 1908 7308 Ribbon unit C769351000 1 B
601 1902 5606 Ribbon detecting lever spring C401351040 1 C
602 1902 5605 Ribbon feeding pawl spring C401351020 1 C
603 1902 5847 Spool gear T C405359030 1 C
604 1902 5848 Spool gear S C405359040 1 C
605 1902 5609 Spool gear breake spring C401351070 1 C
To Next Page
