Casio AL-100R Service Manual

— 13 —
CODE NO. PARTS NAME SPECIFICATION Applicable Q
Price
Code
R REMARKS
1004 5597
LED URUY3117X-J546R Common 36 AH B
1004 5598
LED GL3ZV802B1H6 Common 52 AD B
1004 5599
LED URUY3117X-J545R Common 52 AH B
2370 1407
LED KR3301X-J444K Common 52 AB B
Keyboard unit
1005 2259
KEY ASSY M141175*2 TK(MLMP) Common 1 EV B
20
1004 5531
BLACK KEY M140784-2 Common 36 AH A
21
1005 2300
HAMMER ASSY/BLACK KEY(R) M341438*1 TK(MLMP) Common 9 BH B
21
1005 2301
HAMMER ASSY/BLACK KEY(G) M341439*1 TK(MLMP) Common 9 BH B
21
1005 2309
HAMMER ASSY/BLACK KEY(BK) M341440*1 TK(MLMP) Common 9 BH B
21
1005 2310
HAMMER ASSY/BLACK KEY(BL) M341441*1 TK(MLMP) Common 9 BH B
22
1005 2296
HAMMER ASSY/WHITE KEY(R) M341434*1 TK(MLMP) Common 13 BH B
22
1005 2297
HAMMER ASSY/WHITE KEY(G) M341435*1 TK(MLMP) Common 13 BH B
22
1005 2298
HAMMER ASSY/WHITE KEY(BK) M341436*1 TK(MLMP) Common 13 BH B
22
1005 2299
HAMMER ASSY/WHITE KEY(BL) M341437*1 TK(MLMP) Common 13 BH B
23
6928 4470
RUBBER/CONTACT M240957-2 Common 1 AE A
24
6928 4480
RUBBER/CONTACT M240958-2 Common 6 AH A
25
6928 4490
RUBBER/CONTACT M240959-2 Common 1 AH A
26
1004 5544
WHITE KEY/A M140789-2 Common 7 AL A
27
1004 5545
WHITE KEY/B M140790-2 Common 8 AL A
28
1004 5530
WHITE KEY/C M140783-2 Common 7 AL A
29
1004 5532
WHITE KEY/D M140785-2 Common 7 AL A
30
1004 5533
WHITE KEY/E M140786-2 Common 7 AL A
31
1004 5534
WHITE KEY/F M140787-2 Common 7 AL A
32
1004 5543
WHITE KEY/G M140788-2 Common 7 AL A
33
1004 5547
WHITE KEY/SA M140792-2 Common 1 AR A
34
1004 5546
WHITE KEY/SC M140791-2 Common 1 AR A
35
1004 5551
HOLDER/LED/LMP2-W M341382-1 Common 4 AD C
36
1004 5552
HOLDER/LED/LMP2-B1 M341383-1 Common 1 AE C
37
1004 5553
HOLDER/LED/LMP2-B2 M341384-1 Common 2 AC C
38
1004 5554
HOLDER/LED/LMP2-B3 M341385-1 Common 1 AE C
1004 5550
CAP/GUIDE/WHITE KEY M341380-1 Common 13 AE C
1004 6040
CAP/GUIDE/BLACK KEY M341381-1 Common 36 AA C
1004 5527
CHASSIS SUB ASSY M140831C*2 Common 1 CT C
6927 4161
FELT M440767A-1 Common 1
AL X
6932 4210
FELT M441246-001V01 Common 1
AP X
6932 4211
FELT M441247-001V01 Common 1
BG X
CN Panel assy
43
6924 5260
BUTTON/POWER M340318-1 Common 1 AA B
44
1004 7614
BUTTON/RUBBER M241510-1 Common 1 AB B
45
1004 7628
BUTTON/RUBBER M241503-1 Common 1 AD B
46
1004 7629
BUTTON/RUBBER M241504-1 Common 1 AC B
47
1004 7630
BUTTON/RUBBER M241505-1 Common 3 AA B
48
1004 7631
BUTTON/RUBBER M241506-1 Common 1 AB B
49
1004 7632
BUTTON/RUBBER M241507-1 Common 1 AB B
50
1004 7633
BUTTON/RUBBER M241508-1 Common 1 AE B
51
1004 7634
BUTTON/RUBBER M241509-1 Common 1 AB B
52
1004 7615
BUTTON/TACT M241511-1 Common 4 AH B
53
1004 7616
BUTTON/TACT M241511-2 Common 2 AE B
54
1004 7617
BUTTON/TACT M241511-3 Common 3 AC B
55
1004 7618
BUTTON/TACT M241511-4 Common 3 AB B
56
1004 7619
BUTTON/TACT M241512-1 Common 1 AC B
57
1004 7620
BUTTON/TACT M241512-2 Common 3 AB B
Notes: Q -
Quantity per unit
R -
Rank
ITEM NO.
